SUNNEN PRODUCTS COMPANY
Align Honing Machinery

SV-2400 Series Precision Vertical Honing System

MACHINE SPECIFICATIONS:

It is well suited for a wide range of applications including:
Diameter Range (ID): 19 - 203 mm (.75 - 8 in.)
Workpiece Weight: 900 kg (2000 lbs.)
Maximum Workpiece Length:
SV-410 - 710 mm (24 in.)
SV-460 - 1219 mm (48 in.)
Stroke Motor: DC Servo
Spindle Speeds: 90 to 600 rpm
Spindle Motor: 7,5 kW (10 hp)

FEATURES & BENEFITS
Attractive, long-life, low-maintenance stainless steel enclosure provides a clean working environment and ensures operator safety.
Multiple-spindle configurations available.
Flexible modular column design allows ease of customization for your specific application.
Precision spindle with high torque output belt drive delivers superior bore quality.
Rotary feed system and superior tooling choices (GHSS; GHTS; PH; CV/CK; P20/P28; MPS) deliver extremely precise bores.
Optional T-Slot table and optional elevated fixture frame allow optimal fixturing versatility.
“Lubed-for-life” vertical slide and horizontal slide stroke guide ways ensure superior performance and long, trouble-free life. Auto lubrication system is standard for critical components.
